Plastic injection molding auxiliary machine silent – slow machine side crusher
-The slow crusher runs stably, without noise, dust pollution, and crushes particles evenly.
-The feeding hopper is made of double-layer stainless steel to reduce noise, and is equipped with a transparent PC viewing window for intuitive and convenient viewing of materials.
-Fully open body, easy to disassemble and assemble, quick to clean; no screen design. Equipped with main power isolation switch, high safety.
– Standard cycle timer can automatically control operation and shutdown to save energy.
– Commonly used next to injection molding machines with automatic filling and mixing proportioning valves to form a small automatic immediate recovery system.
– Optional recycling system with feeding fan to achieve immediate mixing of new and old materials.
Product Parameters
| Product Name Model | Unit | TLS-250 | TLS-315 | TLS-410 | TLS-420-1 |
| Crushing diameter | mm | 250*250 | 315*315 | 410*315 | 440*400 |
| Crushing capacity | kg/h | 15-20 | 20-30 | 25-35 | 40-50 |
| Knife | / | 2 | 2 | 3 | 3 |
| Fixed knife | / | 6 | 6 | 8 | 8 |
| Motor power | KW | 1.1 | 1.5 | 2.2 | 3.75 |
| Air pump power | HP | 0.5 | 0.75 | 0.75 | 0.75 |
| Speed | r/min | 23 | 23 | 23 | 23 |
| Electrical Brand | / | Schneider | Schneider | Schneider | Schneider |
| Motor brand | / | Shanghai Yexiang | Shanghai Yexiang | Shanghai Yexiang | Shanghai Yexiang |
| Dimensions | mm | 900*450*1200 | 1120*500*1480 | 1200*500*1560 | 1200*600*1600 |
| Weight | kg | 205 | 275 | 315 | 420 |
